Scrap Equipment

Squalo 4000 Vertical Inclined Shears

Description

Fully transportable, easy set-up. Light or bulky ferrous scrap, railway iron, baled cars, and more are quickly processed for fast loading.

Greatly reduce or eliminate higher cost/less productive excavator shearing

No foundation required; only needs firm level ground

Remote control operation standard; can run manually or fully automatic

Easily transported; machine capable of self loading/unloading

Lighter/loose material is greatly densified before shearing

Reduce or eliminate higher cost/less productive excavator shearing

Choice of electric or diesel power

Parts and service conveniently available in USA

Greatly reduce or eliminate costly and unsafe oxy cutting

Heavy robust design is easy to operate and maintain

Equipment Specification

Length	11,073 mm / 36 ft. 4 in.
Width	6,287 mm / 20 ft. 7 in.
Height	4,477 mm / 14 ft. 8 in.
Nominal Diesel Engine HP	440 HP
Weight	129 US tons / 117 Tonnes
Cutting Throat Width	1,410 mm x 420 mm / 55 in x 15.75 in.
Feed Chute Width	2.65 m / 8 ft. 8 in.

Adjustable	53 cm / 20 in.
Adjustable	80 cm / 31 in.
Adjustable	105 cm / 41 in.
Adjustable	130 cm / 51 in.

Diesel	6 cyl Caterpillar
Electric	Marathon 362 Kw
Electrical Consumption	362 Kwh
Automatic Cycle	30 second cycle
Average Fuel Consumption	10 gallons per hour / 40 liters per hour
Processing Capacity	Up to 46 US tons per hour / 42 Tonnes per hour
Shear Force	716 Tons / 650 M/Tonne

Diesel & Electric power – bears the engine manufacturers warranty.

Structure / Framework – 2 years from date of commissioning

Hydraulic and Electric parts – 1 year from date of commissioning

Any parts replaced under the warranty will be supplied free of charge on an ex-factory Al-jon/Bonfiglioli basis.

*Warranty is void if payment in full is not made in accordance with the invoice terms.
